Product Description
Haier Biomedical Pharmacy Refrigerator (New Generation)
Used for storage of medicines, vaccines, reagents, biological products and other items that require a temperature between 2-8° C in hospitals, pharmacies, pharmaceutical factories, clinics and laboratories etc.
Innovative Design
- Purpose-built for medical and laboratory use
- High performance with low noise level
- Eco-friendly and energy saving
- Condensation free even at ambient 32°C & 80% RH
- Convenient monitoring and data export
Product Features
 |
Low energy consumption: 2.5 kWh/day |
|
 |
Excellent performance: temperature uniformity ≤±1°C | |
 |
Quiet operation: 39dB (A) |
|
 |
Intelligent anti-condensation: triple-paned tempered glass door with door frame heater, effectively reduces condensation even at 32° C, 80% RH ambient temperature |
|
 |
Eco-friendly hydrocarbon refrigerant (R600a) and CFC- free polyurethane insulation for reduced global warming potentia |
|
 |
Hermetically sealed compressor, forced-air circulation with auto defrost to ensure high cooling performance, temperature uniformity ≤±1.5°C; anti- freezing thermostat is available to protect store items from freezing |
|
 |
Microprocessor controller, digital display with 0.1°C resolution; easy to check the min/max temperature in the past 24 hours |
|
 |
Self-closing door with magnetic gasket for positive seal |
|
 |
Multiple alarm functions for safer monitoring |
|
 |
Optional USB, RS485 and printer, easy to export temperature data; all events and alarms will be recorded by the USB module |
|
 |
Energy efficient interior LED lighting, side-mounted to enlighten full space |
|
 |
A φ25mm probe access port is standard on side wall
|
|
 |
Convenient security with a top-mounted unique-key lock |
|
 |
4 swivel casters with 2 leveling feet for easily movement and fixing |
|
 |
Adjustable plastic-coated wire shelves for improved circulation and flexible storage |
Specifications
| Technical Data | Cabinet Type | Upright, Glass Door | |
| Climate Class | N, 16~32ºC | ||
| Cooling Type | Forced Air Cooling | ||
| Defrost Mode | Auto | ||
| Refrigerant | R600a | ||
| Sound Level (dB(A)) | 37 | ||
| Performance | Temperature Range (°C) | 2~8 | |
| Control | Controller | Microprocessor | |
| Display | LED | ||
| Electrical Data | Power Supply (V/Hz) | 115V/60Hz | |
| Electrical Current (A) | 3.4 | ||
| Performance Characteristics |
Temperature Sensor | NTC | |
| Power Consumption (kWh/24h) | 1.85 | ||
| Dimensions | Capacity (L/Cu.Ft) | 461/16.3 | |
| Net/Gross Weight (approx) | (kg) | 115/125 | |
| (lbs) | 254/276 | ||
| Interior Dimensions (W*D*H) | (mm) | 500*590*1670 | |
| (in) | 19.7*23.2*65.7 | ||
| Exterior Dimensions (W*D*H) | (mm) | 595*800*1990 | |
| (in) | 23.4*31.5*78.3 | ||
| Packing Dimensions (W*D*H) | (mm) | 720*930*2100 | |
| (in) | 28.3*36.6*82.7 | ||
| Alarms | High/Low Temperature | YES | |
| High Ambient Temperature | YES | ||
| Door Ajar | YES | ||
| Power Failure | YES | ||
| Low Battery | YES | ||
| Sensor Error | YES | ||
| Communication Failure | YES | ||
| Condenser Heat | YES | ||
| Remote Alarm | YES | ||
| Accessories | Caster | 4 | |
| Foot | 2 | ||
| Porthole | 2 | ||
| Shelves/Drawers | 6 / - | ||
| Printer | Optinal | ||
| USB Interface | Optinal | ||
| RS485 | Optinal | ||
| Material | Exterior Material | Painted Steel | |
| Interior Material | Polystyrene | ||
| Door Thickness (mm) | 50 | ||
| Cabinet Thickness (mm) | 45 | ||
| Others | Certification | CE, DIN13277 (Optional) | |
Warranty Information: 1 year on all parts and 3 years on the compressor.
