Product Description
Helping Make Your Next Great Discovery Possible
The Lx 500 clinical microscope is the outcome of world-class technologies and design innovations. Highly modular and accessory friendly, the Lx 500 is a versatile and fully extendable clinical microscope that boasts graceful symmetry and performance thanks to its ergonomic and optical features.
Lx 500 Advantages:
- RP2 series Infinity Corrected Super Plan optics provide a virtually flat field of view at all magnifications, with pristine contrast and color fidelity. Proprietary MaxLite coatings further enhance optical performance.
- With an optional ergonomic articulating head, viewing angle will conform to the user to provide a more comfortable seated posture.
- A Rackless stage ensures safety and maximizes workspace. A ceramic surface promises scratch resistance during use.
- True Kohler illumination and a standard flip-top condenser guarantee superb contrast from 2.5x to 100x magnification.
- Lighting rechargeable LED (approx. 100,000 hours).
Microscope
| Stand | Single mold sturdy stand with anti rust materials. Extended base for better stability |
| Viewing Body | Trinocular 30°, 360° rotatable, Inter pupillary distance 47 - 75mm with height adjustment |
| Eyepiece | Focusable 10x/22mm widefield eyepieces with foldable eyeguards, antifungal coated |
| Nosepiece | Reverse angle quintuple nosepiece (Ball bearing type) with click stops and rubber grip |
| Objectives | RP2 series Infinity Corrected DIN Plan Achromatic objectives 4x, 10x, 40x (spring loaded), 100x (spring loaded, oil), antifungal coated |
| Mechanical Stage | Rackless X-axis Ceramic double plate stage, size 200 x 160mm, X/Ytravel range 76mm x 50mm. Double specimen holder |
| Condenser | Flip-top sub stage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with blue day light filter. Rack and pinion movements on stainless steel guides |
| Focusing | Co-axial coarse and fine focusing on gear systems for smooth operation. Fine adjustment 0.3mm/rotation |
| Illumination | True Köhler illumination with LED with variable illumination control. |
| Electronics |
Universal input 100V - 240V AC, 50/60 Hz. Built-in voltage stabilizer |
Package Contents
- Power Cable (6ft)
- Cargille Immersion Oil
- Nylon Dust Cover & Cleaning Cloth
- Styrofoam Casing
Accessories (Optional)
- Pointers & Micrometer Reticules
- Phase (Simple & Zernike), Polarizing, Fluorescence and Dark Field Kits
- Dual Viewing Bridge
- Auxiliary Objectives and Eyepieces
- Cord Hanger Kit
- Digital Cameras and Adapters
- Soft Carrying Case
