Product Description
Yamato IC-103C Natural Convection Benchtop Incubator 37L 115V
Economical general purpose benchtop compact design natural convection incubator that improves visibility with a large observation window, 37L 115V 1.8A 50/60Hz. Operating temperature range +5~+80° C
Operation and functions
- Space saving
- The Incubator comes with either an observation window (W) for improved visibility or solid door
- Control panel located at a higher position for easy access
- Easy to use digital setting display and timer
- Air jacket technology ensures even and efficient heat distribution throughout the chamber
- Standard equipped with various functions such as self-diagnostic, calibration off-set, overheat prevention and key lock
Specification
| Model | IC-103C | |||||
| System | Natural convection | |||||
| Operating Temp. Range | Room temp. +5~80°C | |||||
| Temp. Control Accuracy | ±0.5°C (at 37°C) | |||||
| Temp. Distribution Accuracy | ±1.0°C | |||||
| Interior | Stainless steel | |||||
| Exterior | Cold rolled steel plate with melamine resin baking finish | |||||
| Heat Insulator | Glass fiber | |||||
| Heater | Stainless steel heating pipe, 0.2kW | |||||
| Temperature Controller | PID control by microprocessor | |||||
| Temperature Setting System | Operation menu key and digital setting by ▲▼ keys, digital display | |||||
| Temperature Display | Measurement temperature: Digital display by 4 digit green LED / Setting temperature: Digital display by 4 digit red LED | |||||
| Timer | 1 min. ~ 99 hrs 59 mins. and 100~999 hrs 50 mins (including timer waiting function) | |||||
| Operation Function | Fixed temperature, Auto start, Auto stop, Quick Auto stop | |||||
| Additional Function | Calibration off-set, Key-lock, Power outage compensation | |||||
| Safety Device | Self diagnostic functions, temp. sensor error, display error, measurement temp. error, auto overheat prevention | |||||
| Heater Control Circuit | SSR drive system | |||||
| Sensor | K-thermocouple | |||||
| Internal Dimensions WxDxH | 350 x 300 x 360 mm | |||||
| External Dimensions WxDxH | 430 x 397 x 606 mm | |||||
| Internal Capacity | 37L | |||||
| Inner Door | None | |||||
| Shelf Load Capacity | ~33 lb/pc. | |||||
| Shelf Rest Step Number | 8 steps | |||||
| Power Supply (50/60 Hz) | AC115V 1.8A (with plug) | |||||
| Weight | ~38 lb | |||||
| Shelf / Shelf Brackets | Stainless steel 2 pcs. / 4pcs. | |||||
| Optional Items | Stand, Stacking kit, Additional shelf, Cable hole (25/50mm or 30/50mm), External communication terminal (RS485), Temp. output terminal, Time-up output terminal for alarm device | |||||
