Product Description
The Yamato BOG-210 is a compact 2.2 L oil bath with integrated magnetic stirring, holding ±0.3 °C at 200 °C while the stirrer runs. That accuracy is the point: it is stirring that makes it possible, because an unstirred oil bath stratifies and the reading at the probe stops describing the flask.
This is the glass bath version. You can see the flask, the oil level and whether anything is boiling or changing colour without lifting the vessel out. Control range runs to 240 °C.
Key Features
- Hard transparent glass bath — watch the reaction
- ±0.3 °C at 200 °C with stirring
- Setting range 0 to 260 °C, control ambient +5 °C to 240 °C
- Integrated magnetic stirring with PTFE stirrer included
- 2.2 L maximum, 1.7 L recommended fill
- Heater guard included — protects against contact with the element
- Compact footprint, 2.8 kg (6 lb)
Technical Specifications
| Specification | BOG-210 |
|---|---|
| Type | Constant temperature laboratory oil bath with magnetic stirring |
| Bath material | Hard transparent glass |
| Temperature setting range | 0 °C to 260 °C |
| Temperature control range | Room temp. +5 °C to 240 °C |
| Temperature control accuracy | ±0.3 °C (at 200 °C, while stirring) |
| Control method | PID control |
| Setting method | Digital setting by ▲▼ keys, 1 °C resolution |
| Heater | Stainless steel tube heater, 425 W |
| Maximum oil volume | 2.2 L |
| Recommended oil volume | 1.7 L |
| Bath dimensions | ø170 × 140 mm |
| Power source | AC220V 2.5A, 50/60 Hz |
| Unit weight | 2.8 kg (6 lb) |
| Shipping weight | 12 lb |
| Fuse | 6.3 A with short circuit and overcurrent protection |
| Manufacturer part number | BOG-210 |
| GTIN | 797059932634 |
| Country of origin | China |
Safety Features
- Independent overheat prevention device
- Heater guard
- Self-diagnostic functions with temperature sensor error detection
- 6.3 A fuse with short circuit and overcurrent protection
What’s Included
- Heater guard
- Arbor and PTFE stirrer
- Connector cap and cable ties
- Instruction manual
- One year manufacturer warranty
Note on bath fluid
Heat transfer oil is not included. Choose a fluid rated above your working temperature; silicone oil is the usual choice at this range. Fill to the recommended 1.7 L — oil expands as it heats, and never run the bath dry.
Compliance
- Manufactured under ISO 9001:2015, ISO 14001:2015 and ISO 45001:2018
For quotations, freight, bath fluids and volume pricing, contact Pro Lab Supply.
