Product Description
The Streamline® SLC-RABS is a closed restricted access barrier system for sterile compounding. This positive-pressure configuration is a compounding aseptic isolator for non-hazardous sterile preparations under USP <797>. The work zone is held above room pressure, so unfiltered room air cannot work its way into the critical area.
H14 supply and exhaust filtration holds the main chamber and the pass-through at ISO Class 5. Work zone air is changed 20 to 30 times per minute and recovers to ISO Class 5 in under three minutes after a worst-case contamination event.
The 4 ft unit is operated through two oval gloveports with safe-change cuff rings, so gloves can be replaced mid-process without opening the work zone. The airlock pass-through uses a vertical sliding door with an electrical interlock that prevents both doors being open at once.
This configuration ships with a plain work tray, without sharps disposal. The matching −S configuration adds waste chute openings and sharps containers.
A motorized height-adjustable stand (SHM-4A2) is included, not a separate line on the quote.
Specifications
| Nominal Size | 4 ft (1.2 m) |
|---|---|
| External Dimensions, cabinet only (W x D x H) | 52.8" x 32.6" x 50.8" |
| External Dimensions, on the included motorized stand | 59.2" x 32.6" x 77.4" to 89.4" |
| Main Chamber Work Zone (W x D x H) | 33.1" x 24.0" x 26.4" |
| Pass-Through (W x D x H) | 13.9" x 24.0" x 26.4" |
| Gloveports | 2 oval, with safe-change cuff rings |
| Work Zone and Pass-Through Performance | ISO Class 5 (Class 1, Federal Standard 209E) |
| Downflow and Exhaust Filters | HEPA H14, EN 1822 and IEST-RP-CC001.3 |
| Typical Filter Efficiency | >99.995% for particle size between 0.1 and 0.3 micron |
| Inlet Pre-Filter | 80% efficient |
| Air Changes | 20 to 30 per minute |
| Illumination | ≥ 800 Lux, LED |
| Electrical | 120-110 V, AC, 60 Hz, 1Ø |
| Full Load Amps | 4.0 A |
| Nominal Power | 264 W |
| Heat Load | 901 BTU |
| Main Body | 1.2 mm / 18 gauge electro-galvanized steel, Isocide™ antimicrobial powder coat |
| Work Tray | 1.5 mm / 16 gauge stainless steel 304, 4B finish |
| Side Walls | 1.2 mm / 18 gauge stainless steel 304, 4B finish |
| Shipping Weight | 840 lb |
| Shipping Dimensions, maximum | 62.6" x 39.0" x 87.0" |
| Shipping Volume, maximum | 122.9 cu ft |
| Warranty | 1 year, excluding consumable parts and accessories |
Standards
CETA CAG-001-2005 · CETA CAG-002-2006 · ISO 14644-1 Class 3 at rest, Class 5 in operation · EU GMP Grade A · EN-1822 · IEST-RP-CC001.3 · IEST-RP-CC007 · IEST-RP-CC034.1 · IEC 61010-1 · EN 61010-1 · UL 61010-1 · CAN/CSA-22.2 No. 61010-1
What’s Included
- Esco Streamline SLC-RABS isolator, 4 ft / 1.2 m
- Motorized height-adjustable stand SHM-4A2
- 2 oval gauntlets with sleeves
- Plain work tray
- 1 GFCI outlet — cabinet and GFCI run on a single power cord
- AC fans, 110 V / 60 Hz
Accessories
| Model | Description | Price |
|---|---|---|
| 5170224 | Sharps disposal container with mounting base, 5.0 qt (10.5" x 7.5" x 18") — maximum 2 per unit | Contact us |
