Product Description
-30℃ Biomedical Freezer DW-30L818BP
Features
Large Capacity and innovative design.
Typical installations and applicaitons are blood banks, hospitals research institutes, electronic, chemical and other industries, cryopreservation of plasma, biologics and other products, and cold tests for components and materials.
Energy saving with variable speed inverter technology
Optimized refrigeration system with a high efficiency inverter compressor to reduce energy consumption
Excellent temperature uniformity in a large storage space
eatures built-in evaporator, large storage space, and adjustable shelf, providing faster temperature pulldown and a better temperature uniformity of set point +/- 3℃.
Low noise
Sound attenuation design to reduce the sound level to 37 dba at 220 V/50 Hz
Environment Friendly
HC refrigeration system contains zero chlorine and fluorine. I t does not harm the environment.
Urethane foam insulation complies with European ROHS regulation
Product Features
- Micrprocessor Control system
- Microprocessor-based temperature control. Large LED displays cabinet temperature with 0.1 C resolutions. The temperature range is -10oC to -30oC.
- Cabinet temperature, ambient temperature and voltage are shown on the panel.
- Alarm conditions include high and low temperature, sensor error, power failure, and low battery, door ajar and high ambient.
- Alarm modes are audible and flashing lights. Remote alarm termin als are available.
- Battery supports display and alarm system for forty eight hours after power outage.
- RS485
- Optional features are IoT module, USB port, and swipe card functions.
- Insulation
- 70 mm thick insulation.
- Optional inner doors for better thermal efficiency.
- Porthole
- Two standard portholes allow ease of temperature testing.
- Security Lock
- Padlock is standard. Magnetic lock is optional. Both provide security and independency.
- Temperature Recorder
- Optional temperature recorder for temperature recording and preservation
Product Advantages
- Microprocessor temperature control: LED displays cabinet temperature with 0.1 ℃ resolution, ambient temperature, and input voltage.
- Ergonomic handle design: easy access to storage space, built in lock and padlock features.
- Casters and leveling legs for ease of maneuvering and positioning.
- Power coating galvanized interior with large round corner design，corrosion resistance and easy to clean
- Adjustable shelves made with stainless steel or coated steel.
- Inner door design reduces loss of cold air to improve energy efficiency and stable temperature.
- Pressure equalization port for easy door opening.
- Double door seals for better insulation performance.
- Optional USB port allows users to download temperature data saved up to 10 years for compliance and auditing purposes.
- Ergonomic Design: document holding compartment for storing size A4 paper and pens.
| DW-30L818BP | |
| Cabinet Type | Upright |
| Climate Class | 4 |
| Cooling Type | Direct cooling |
| Defrost Mode | Manual |
| Temperature Range(℃) | -10~-30 |
| Capacity(L/Cu.Ft) | 818/28.8 |
| Exterior Dimension(W*D*H)(mm) | 988*951*1980 |
| Exterior Dimension(W*D*H)(in) | 38.9*37.44*77.95 |
