Product Description

Cameras Vega

The super resolution Vega camera is a 6 MP high-definition CMOS solution that boasts one of the fastest frame rates in its class, superb contrast, and unparalleled accuracy in color reproduction. This digital solution offers HD video streaming, digital, and an SD card interface in one highly affordable package. Additionally, measurement, calibration, and parameter settings may be controlled through HDMI with the help of a USB mouse provided with the system. Total vertical integration of our camera means better image quality, easy to navigate software, and better end-to-end software and driver support.

• Sensor: 1/2.8” 6.0 MP Color CMO

• Sensor resolution: Dynamic 1920x1080 pixels Static 3264x1836 pixels

• A/D conversion: 24 Bit RGB

• Interface: USB 3.0, HDMI, SD card, mouse control

• Active area: 5.70mm x 4.28mm

• Frame rate : 30 fps (@1080p)

• Optical connection: C- Mount

• Pixel Size: 2.7μm x 2.7μm

• Dynamic range: 65 dB

• Measurement: Yes

• Software Requirements: Microsoft Windows (XP and later versions) / Linux / Mac

• Pixel clock: 48 MHz

• Image processing: High speed FPGA, progressive scan, advanced noise reduction

• Ambient conditions: Operating Temperature: 0-60˚C Humidity: 45-85%

• Voltage: AC power (universal)

• Power indication: Green LED indicating power on and ready for capture

• Exposure: 1ms-1s auto/manual, white balancing, electronic rolling shutter

What is in the Box?

1 x Camara Vega
