Product Description
The Yamato DR-201-115V is a high temperature natural convection oven with a control range of 300 to 700 °C. That upper limit is what makes it a different instrument from a drying oven: at 700 °C you are doing ashing, binder burnout, heat treatment of small metal parts and ceramics work, not drying glassware.
It sits in the gap between a 260 °C laboratory oven and a muffle furnace — a chamber you can programme over 30 steps, with a stainless interior rather than refractory brick, in a 520 mm wide benchtop cabinet.
Key Features
- 300 to 700 °C control range, ±5 °C at 700 °C
- Reaches 700 °C in about 70 minutes
- 6 programme patterns with step weight, repeat, hold and skip
- Ceramic fibre and rock wool insulation
- Stainless steel chamber, 13.75 L
- Double K thermocouple
- Calibration offset, keypad lock and auto resume after power failure
Technical Specifications
| Specification | DR-201-115V |
|---|---|
| System | Natural convection, high temperature |
| Temperature control range | 300 °C to 700 °C |
| Temperature control accuracy | ±5 °C (at 700 °C) |
| Temperature fluctuation | 10 °C (at 700 °C) |
| Temperature distribution accuracy | ±25 °C (at 700 °C) |
| Temperature gradient | 30 °C (at 700 °C) |
| Temperature rise time | Approx. 70 min (room temp. +5 °C to 700 °C) |
| Temperature fall time | Approx. 150 min (700 °C to 300 °C) |
| Internal capacity | 13.75 L |
| Internal dimensions (W × D × H) | 250 × 250 × 220 mm |
| External dimensions (W × D × H) | 520 × 443 × 612 mm (protrusions excluded) |
| Interior material | Stainless steel sheet metal |
| Exterior material | Chromium-free electrogalvanized steel sheet, baked finish |
| Heat insulating material | Ceramic fibre and rock wool |
| Heater | Iron-chrome wire heater, 1.3 kW |
| Temperature controller | PID control by microcomputer |
| Sensor | K thermocouple (double sensor) |
| Program modes | 6 patterns — PrG1: 30 steps, PrG2–3: 15 steps, PrG4–6: 10 steps |
| Program functions | Step weight, repeat, step hold and step skip |
| Operation modes | Fixed temperature, program, program auto start, auto start, quick auto stop, auto stop |
| Timer | 0 to 99 h 59 min, and 100 h to 999 h 50 min, with wait function |
| Additional functions | Calibration offset, keypad lock, auto resume mode select |
| Shelf load capacity | 15 kg per shelf · 30 kg total |
| Shelf positions / pitch | 3 steps / 33 mm |
| Shelf plate | Perforated stainless steel |
| Power source | AC115V 11.5A, 50/60 Hz (with plug) |
| Unit weight | Approx. 36 kg (79 lb) |
| Shipping weight | 111 lb |
| Manufacturer part number | DR-201-115V |
| GTIN | 797059932146 |
| Country of origin | China |
Safety Features
- Self-diagnostics: automatic overheat prevention, sensor failure, heater disconnection, SSR short circuit, main relay failure, memory error, internal communication error and abnormal temperature reading
- Independent overheat prevention device
- Overcurrent earth leakage breaker
What’s Included
- Perforated stainless steel shelf plates (2 pcs.)
- Instruction manual
- One year manufacturer warranty
Note on placement
At 700 °C the exterior and the area above the oven get hot. Allow clearance around the cabinet and do not place heat-sensitive equipment or reagents above it.
Compliance
- Manufactured under ISO 9001:2015, ISO 14001:2015 and ISO 45001:2018
- US Harmonized Tariff code 8514.19.0000 · ECCN EAR99
